Multistrada V4

Starting from £16,995.00

Enquire about this model

Make an Enquiry Test Ride Enquiry Part Exchange Enquiry
Return to Model Categories

Description & Specification


Rewrite travel rules

Get ready to discover the fourth Multistrada generation. Sportier and more touring, stronger in off-road use and easier in urban action. Lightweight and compact, with the new 170 HP V4 Granturismo engine for a sporty and exciting ride on mixed terrain.

Ready for long journeys thanks to the navigation-system that can be viewed on the dashboard and the innovative rider assistance radar-system, it will offer you excellent riding comfort and a main service-interval only after 60,000 km, the Oil Service, are now scheduled at 15,000 km or 24 months. After getting back from your adventures, it will offer you ease and confidence in everyday use thanks to state-of-the-art electronic rider assistance systems and sophisticated ergonomics, including an adjustable seat height of up to 790 mm thanks to the low seat and low suspension kit, both available as accessories.

  • Frame

    Frame

    Aluminum monocoque frame

    Rake

    24.5°

    Front Wheel

    Light alloy cast, 3" x 19"

    Front Tyre

    Pirelli Scorpion Trail II 120/70 ZR 19

    Rear Wheel

    Light alloy cast, 4.5" x 17"

    Rear Tyre

    Pirelli Scorpion Trail II 170/60 ZR 17

    Fuel Tank Capacity

    22 l (5.8 US gal)

    Dry Weight

  • Dimensions

    Wheelbase

    1,567 mm (61.7 in)

    Front Wheel Travel

    170 mm

    Rear Wheel Travel

    180 mm (6.7 in / 7.1 in)

    Seat Height

    Adjustable, 840 mm - 860 mm (33.1 in - 33.9 in)

    Bore x Stroke

    83 mm x 53.5 mm

    Compression Ratio

    14.0:1

  • Suspension

    Front Suspension

    Ø 50 mm fully adjustable usd fork

    Rear Suspension

    Fully adjustable monoshock, Remote spring preload adjustment, aluminium double-sided swingarm

  • Brakes

    Front Brake

    2 x Ø 320 mm semi-floating discs, radially mounted Brembo monobloc 4-piston 2-pad callipers, radial master cylinder, Cornering ABS

    Rear Brake

    Ø 265 mm disc, Brembo 2-piston floating calliper, Cornering ABS

  • Performance

    Engine Type

    V4 Granturismo, V4 - 90°, 4 valves per cylinder, counter-rotating crankshaft, Twin Pulse firing order, liquid cooled

    Displacement

    1,158 cc (71 cu in)

    Power

    170 hp (125 kW) @ 10,500 rpm

    Torque

    12.7 kgm (125 Nm, 92 lb ft) @ 8,750 rpm

    Exhaust

    Stainless steel muffler, double catalytic converter and 4 lambda probes

    Gearbox Type

    6 speed

    Gearbox Ratio

    1=40/13, 2=36/16, 3=34/19, 4=31/21, 5=29/23, 6=27/25

    Primary Drive

    Straight cut gears, ratio 1.8:1

    Final Drive

    Chain, front sprocket z16, rear sprocket z42

    Clutch

    Multiplate wet clutch with hydraulic control, self-servo action on drive, slipper action on over-run

    Battery
